jKanban

Javascript plugin for Kanban boards

Support this plugin!

jKanban allow you to create and manage Kanban Board in your project!

Please try out the live demo!

Install

Clone the repo and use the javascript and the css files in the dist folder.

You have to include

<link rel="stylesheet" href="path/to/jkanban.min.css">

and

<script src="path/to/jkanban.min.js"></script>

in your page and you are done.

Usage

Init jKanban is a piece of cake!

var kanban = new jKanban(options)

Here's an overview of the default values.

var kanban = new jKanban({
    element         : '',                                           // selector of the kanban container
    gutter          : '15px',                                       // gutter of the board
    widthBoard      : '250px',                                      // width of the board
    responsivePercentage: false,                                    // if it is true I use percentage in the width of the boards and it is not necessary gutter and widthBoard
    boards          : [],                                           // json of boards
    dragBoards      : true,                                         // the boards are draggable, if false only item can be dragged
    addItemButton   : false,                                        // add a button to board for easy item creation
    buttonContent   : '+',                                          // text or html content of the board button
    click           : function (el) {},                             // callback when any board's item are clicked
    dragEl          : function (el, source) {},                     // callback when any board's item are dragged
    dragendEl       : function (el) {},                             // callback when any board's item stop drag
    dropEl          : function (el, target, source, sibling) {},    // callback when any board's item drop in a board
    dragBoard       : function (el, source) {},                     // callback when any board stop drag
    dragendBoard    : function (el) {},                             // callback when any board stop drag
    buttonClick     : function(el, boardId) {}                      // callback when the board's button is clicked
})

Now take a look to the boards object

[
    {
        "id"    : "board-id-1",               // id of the board
        "title" : "Board Title",              // title of the board
        "class" : "class1,class2,...",        // css classes to add at the title
        "dragTo": ['another-board-id',...],   // array of ids of boards where items can be dropped (default: [])
        "item"  : [                           // item of this board
            {
                "id"    : "item-id-1",        // id of the item
                "title" : "Item 1"            // title of the item
            },
            {
                "id"    : "item-id-2",
                "title" : "Item 2"
            }
        ]
    },
    {
        "id"    : "board-id-2",
        "title" : "Board Title 2"
    }
]

WARNING: all ids are unique!

About custom properties

jKanban also support custom properties on items to improve your applications with html data- properties. You can define them at like:

[
    {
        "id"    : "board-id-1",
        "title" : "Board Title",
        "item"  : [
            {
                "id"      : "item-id-1",
                "title"   : "Item 1",
                "username": "username1"
            },
            {
                "id"      : "item-id-2",
                "title"   : "Item 2",
                "username": "username2"
            }
        ]
    }
]

Which jKanban will convert to:

<main class="kanban-drag">
    <div class="kanban-item" data-eid="item-id-1" data-username="username1">Item 1</div>
    <div class="kanban-item" data-eid="item-id-2" data-username="username2">Item 2</div>
</main>

API

jKanban provides the easiest possible API to make your boards awesome!

Method Name	Arguments	Description
addElement	boardID, element	Add element in the board with ID boardID, element is the standard format
addForm	boardID, formItem	Add formItem as html element into the board with ID boardID
addBoards	boards	Add one or more boards in the kanban, boards are in the standard format
findElement	id	Find board's item by id
findBoard	id	Find board by id
getBoardElements	id	Get all item of a board
removeElement	id	Remove a board's element by id
removeBoard	id	Remove a board by id

Example

Clone the repo and look in the example folder

Thanks

jKanban use dragula for drag&drop

Develop

Clone the repo then use npm install for download all the dependencies then launch npm run build for build the project

Pull Requests?

I'd love them!

Comments?

Let's hear them! (The nice ones please!)

Me?

In case you're interested I'm @riktarweb
