lavu-grid

The lavu-grid is a Polymer 1.x Responsive Grid and defines a container for html elements with role="cell" or lavu-cell custom elements.

CSS from Material Design Lite grid is used as a base, so a large part of the documentation is copy pasted from the Material Design Lite layout GRID section.

Introduction

The lavu-grid grid component is a simplified method for laying out content for multiple screen sizes. It reduces the usual coding burden required to correctly display blocks of content in a variety of display conditions.

A grid has 16 columns in the large (desktop) screen size, 12 in the medium (desktop) size, 8 in the small (tablet size), and 4 in the extra small (phone) size, each size having predefined margins and gutters set via custom css properties. Cells are laid out sequentially in a row, in the order they are defined, with some exceptions:

• If a cell doesn't fit in the row in one of the screen sizes, it flows into the following line.
• If a cell has a specified column size equal to or larger than the number of columns for the current screen size, it takes up the entirety of its row.

Style the lavu-grid as desired (colors, font size, maximum width, etc.), by setting CSS properties in --lavu-grid mixin. By setting a max-width CSS property in --lavu-grid mixin, the grid stays centered with padding on either side.

Demo and Documentaion

See the component page.

Install

Install the component using Bower:

$ bower install leifoolsen/lavu-grid --save

Usage

Import Custom Element:

<link rel="import" href="../bower_components/lavu-grid/lavu-grid.html">

Start using it:

<lavu-grid>
  <div role="cell">4</div>
  <div role="cell">4</div>
  <div role="cell">4</div>
  <div role="cell">4</div>
</lavu-grid>

This example renders a grid with four cells. Each cell spans four columns.

Listen to media query changes (optional):

<lavu-grid on-media-query-changed='_mediaQueryChanged'>
  ...
</lavu-grid>

<script>
  ...
  _mediaQueryChanged: function(e) {
    if(this.$$('lavu-grid:first-child') == e.target) {
      console.log('media-query-changed: '
        + e.detail.screenClass + ', ' + e.detail.mediaQuery);
    }
  }
</script>

Change default media query values (optional)

<lavu-grid media-queries='
  { "queryXs": "(max-width: 768px)",
    "querySm": "(min-width: 769px) and (max-width: 991px)",
    "queryMd": "(min-width: 992px) and (max-width: 1199px)",
    "queryLg": "(min-width: 1200px)"
  }' >
  ...
</lavu-grid>

Running locally

polyserve

$ npm install --global polyserve

$ polyserve

License

Licensed under the Apache License, Version 2.0 (the "License"); you may not use this software except in compliance with the License.

Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.

TODO

• Tests
